DSP |
• Texas Instruments TNETV2510GGW for PVDM2-16, PVDM2-32, PVDM2-48, and PVDM2-64 • Texas Instruments TNETV2505GGW for PVDM2-8 |
|
DSP CPU Clock |
• 200 MHz for TNETV2510GGW • 175MHz for TNETV2505GGW |
|
DSP External Memory |
128-megabit synchronous dynamic RAM for each DSP (for both TI 2510 and TI 2505) |
|
Interface |
80-pin SIMM interface |
|
Features |
|
|
Echo Cancellation |
Software echo cancellation compliant with ITU-I G.168, with 64-ms tail coverage |
|
Approvals and Compliance |
|
|
Safety |
• IEC 60950 (worldwide) and AS/NZS 3260 (Australia and New Zealand) • CAN/CSA-C22.2 No. 60950 (Canada) and GB4943-95 (People's Republic of China) • EN60950 (CENELEC; includes EU and EFTA) • SS337 (Singapore; PSB approval), NOM-019-SCFI-1998 (Mexico), and UL 60950 3rd edition (United States) |
|
Homologation |
Platform dependent |
|
Mean Time between Failure (MTBF) |
System dependent |
|
EMC |
|
|
CISPR22, Class B |
Emissions |
|
EN55022, Class B |
Emissions |
|
CFR47, Part 15, Subpart B, Class B |
Emissions |
|
EN61000-3-2 |
Harmonics |
|
EN61000-3-3 |
Flicker |
|
CISPR24 |
Immunity |
|
EN 55024 |
Immunity |
|
EN50082-1 |
Immunity |
|
EN61000-3-2 |
Harmonics |
|
EN 61000-3-3 |
Flicker |
|
EN 61000-4-2 |
Electrostatic discharge (ESD) |
|
EN 61000-4-3 |
Radio frequency (RF) fields |
|
EN 61000-4-4 |
EFT |
|
EN 61000-4-5 |
Surge |
|
EN 61000-4-6 |
Conducted RF |
|
EN 6100-4-8 |
Power-frequency magnetic fields |
|
EN 61000-4-11 |
Voltage dips, sags, and interruptions |
