Software Features
Stackability
• Virtual Stacking Support
• D-Link Single IP Management
• Up to 32 devices per virtual stack
• Up to 20G stacking bandwidth
• Physical Stacking
• Supports Duplex Chain/Ring topology
• Up to 40G stacking bandwidth full duplex
• Up to 6 units per stack
L2 Features
• MAC Address Table: 16K
• Flow Control
• 802.3x Flow Control
• HOL Blocking Prevention
• Jumbo Frame up to 9000 Bytes
• IGMP Snooping
• IGMP v1/v2/v3 Snooping
• IGMP v3 awareness
• Supports 512 IGMP groups
• Supports 128 static multicast addresses
• IGMP per VLAN
• Supports IGMP Snooping Querier
• Host-based IGMP Snooping Fast Leave
• MLD Snooping
• Supports MLD v1/v2 awareness
• Supports 512 groups
• Supports 128 Static Multicast Addresses
• Per VLAN MLD Snooping
• Host-based MLD Fast Leave
• MLD Snooping Querier
• Spanning Tree Protocol
• 802.1D STP
• 802.1w RSTP
• 802.1s MSTP
• Loopback Detection
• 802.3ad Link Aggregation
• Max. 32 groups per device/8 ports per group
• Port Mirroring
• Support 4 mirroring groups
• One-to-One, Many-to-One
• Supports Mirroring for Tx/Rx/Both
• Multicast Filtering
• Forwards all unregistered groups
• Filters all unregistered groups
• LLDP, LLDP-MED
VLAN
Quality of Service (QoS)
• 802.1p Quality of Service
• Queue Handling
• Strict
• Weighted Round Robin (WRR)
• 8 queues per port
• Bandwidth Control
• Port-based (Ingress/Egress, min. granularity for 10/100/1000 BASE-T ports is 64 Kb/s)
• CoS based on
• 802.1p priority
• VLAN
• MAC address
• Ether type
• IP address
• DSCP
• Protocol type
• TCP/UDP port number
• DSCP of IPv6 Traffic Class
• IPv6 flow label
L3 Features
• ARP
• 256 Static ARP
• Supports Gratuitous ARP
• IPv6 Neighbour Discovery (ND)
• Default Routing
• Static Routing
• 64 IPv4 Static Route Entries
• 32 IPv6 Static Route Entries
Access Control List (ACL)
• ACL based on
• 802.1p priority
• VLAN
• MAC address
• Ether type
• IP address
• DSCP
• Protocol type
• TCP/UDP port number
• DSCP of IPv6 Traffic Class
• IPv6 flow label
• ACL Actions
• Permit
• Deny
• Max. 256 access list
• Max. 768 rules
• Single or multiple ports (each rule)
• Time-based ACL
• ACL Statistics
