ENTEGRON 4 PORT 100M POE SWITCH + 2 FE UPLINK ENTDPS6204P-2F

Interface

4x 10/100Mbps RJ45 Ports +2x10/100 Mbps RJ45 Ports AUTO Negotiation/AUTO MDI/MDIX

Network Media

10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) 100BASE-TX: UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m)

PoE Ports (RJ45)

Standard: 802.3 af/at compliant PoE                                Ports: Port1- Port 4

Voltage

Input Power48-53V.output Power 48V

Backbound Bandwidth

1.6Gbps

Mac Address Table

4K

Dimensions ( W x D x H )

PCB size (12.5*5.8cm)

Environment

Operating Temperature: -10°C~70°C Storage Temperature: -40°C~70°C (-40°F~158°F)                    Operating Humidity: 10% ~ 90% non-condensing Storage Humidity:5%~90% non-condensing

Certification

CE, FCC, RoHS
