Full Gigabit access
Comprehensive safety protection system
Powerful VLAN capabilities
IEEE, 802.1Q, VLAN
Rich QoS strategy
3 priority modes based on port, IEEE802.1p and DSCP
Multilevel access control policy
Reliability design
STP/RSTP/MSTP two layer link protection technology,IGMP Snooping technology
Secure network management and maintenance
CLI command line (Console, Telnet), Web network, SNMP (V1/V2c/V3, SSH (V1/V2) and other management methods
Model | ES2000ENTG8G-4TCM | |
Product | 8G+ 4 Gigabit COMBO Port Managed Ethernet Switchh | |
Port | 8*10/100/1000M Base-TX port | |
4 COMBO | ||
Bandwidth | 128G | |
CPU | 500MHz | |
RAM | 128M | |
FLASH | 16M | |
Management | STP/RSTP/EPPS/EAPS/IEEE 802.3ad... | |
FLASH | 16M | |
RAM | 128M | |
Bandwidth | 20/56Gbps | |
Packet Forwarding | 14.44Mpps | |
MAC Address | 8K | |
IEEE 802.3 | ||
IEEE 802.3u 100BASE-TX | ||
IEEE 802.3ab1000BASE-T | ||
IEEE 802.3x | ||
IEEE 802.3z 1000BASE-X | ||
Network Protocol | IEEE 802.3ad | |
IEEE 802.3q 、IEEE 802.3q/p | ||
IEEE 802.1w、IEEE 802.1d 、IEEE 802.1S | ||
STP(Spanning Tree Protocol) | ||
RSTP/MSTP( Rapid Spanning Tree Protocol) | ||
EPPS ring network protocol | ||
EAPS ring network protocol | ||
Port Specification | 10/100/1000BaseT（X）Auto | |
Transmission Mode | Store and Forward(full wirespeed) | |
10BASE-T ： Cat3,4,5 UTP(≤250 meter) | ||
Transmission Distance | 100BASE-TX ： Cat5 or later UTP(≤100 meter) | |
1000BASE-TX ： Cat6 or later UTP(≤1000 meter) | ||
PWR:Power LED | ||
LED Indicator | SYS:(System LED) | |
Port:(Green=100M LED+Orange=1000M LED） | ||
Built-in power AC 100~240V 50/60HZ | ||
Power | MAX Current 0.2A | |
MAX Power 15W | ||
Operating | -20～+55°C；5%～ |
