Fluke 28 II Ex Kendinden Emniyetli True-RMS Dijital Multimetre

Name: Fluke 28 II Ex Kendinden Emniyetli True-RMS Dijital Multimetre
Brand: FLUKE
SKU: T7387
Price: 116820.00 TRY
Availability: InStock

Ürün Kodu : Fluke 28 II Ex

97.350 TL + KDV

Fiyat Alarmı

Listeye Ekle Tavsiye Et

4-1/2 digit mode for precise measurements (20 000 counts)
True-rms ac voltage and current for accurate measurement on nonlinear signals
Measures up to 1000 V and 10A AC and DC (note that Ex zones require reduced measurements)
Low pass filter ensures accurate voltage and frequency measurements on variable speed motor drives (VSDs)
Frequency to 200 kHz and % duty cycle to help you diagnose VSDs and switching power supplies
Resistance, continuity and diode test
10 000 μF capacitance range for components and motor caps
Conductance measurements for high resistance or leakage tests
Min/Max-Average and Peak capture to record transients and variations automatically
Relative mode to remove test lead interference on resistance measurements
Auto and manual ranging for maximum flexibility
Input Alert protects you by chirping and flashing “Lead when leads are plugged into the wrong inputs

Easy to use

Important extras keep you productive all day long in less than optimal conditions.

Backlit keypad buttons provide extra visibility in poorly lit areas, even when you’re wearing full PPE
Large display digits and 2-level bright white backlight also increases visibility
Long battery life – 400 hours typical without backlight (Alkaline)
Optional magnetic hanger for easy setup and viewing while freeing your hands for other tasks

Easy to service in the field

Access to the separate battery compartment makes it easy to change batteries or fuses without jeopardizing instrument calibration.

Accuracy Specifications
Accuracy specifications are shown as ±(% of reading + number of digits)
DC voltage	Range	0.1 mV to 1000 V
	Accuracy	±(0.05% + 1)
AC voltage	Range	0.1 mV to 1000 V
	Accuracy	±(0.7% + 4)
DC current	Range	0.1 μA to 10 A
	Accuracy	±(0.2% + 4)
AC current	Range	0.1 μA to 10 A
	Accuracy	±(1% + 2)
Resistance	Range	0.1 Ω to 50 MΩ
	Accuracy	±(0.2% + 1)
Conductance	Range	60.00 nS
	Accuracy	±(1.0% + 10)
Diode test	Range	2.0 V
	Accuracy	±(2.0% + 1)
Duty cycle	Range	0.0% to 99.9%
	Accuracy	Within ±(0.2% per kHz + 0.1%) for rise times <1 µs
Capacitance	Range	10 nF to 9999 μF
	Accuracy	±(1% + 2)
Frequency	Range	0.5 Hz to 199.99 kHz
	Accuracy	±(0.005% + 1)
Temperature	Range	-200°C to +1090°C (-328°F to +1994°F)
	Accuracy	±(1% + 10)°C [±(1% + 10)°F]
Display counts	6000 counts/19,999 counts in high-resolution mode
Peak capture	Record transients up to 250 us
Min/Max/Avg recording	Display signals up to approximately 100 ms
Accuracy specifications are shown as ±(% of reading + number of digits)
Safety Certifications
ATEX	{Ex} II 2G Ex ia IIC T4 Gb
	{Ex} I M1 Ex ia I Ma
NEC-500	Class I, Div 1, Groups A-D, 130°C
IECEx	Ex ia IIC T4 Gb
	Ex ia I Ma
GOST R Ex	1Ex ia IIC T4 Gb X
	PO Ex ia I Ma X
	IP6X
General Specifications
Power
	Three AAA batteries
	Battery life: 400 hours
Display	LCD, with backlight
External protection	Rubber holster
Warranty	Three years
Size with holster (H x W x L)	6.4 x 10.0 x 19.8 cm (2.5 x 3.9 x 7.8 in)
Weight with holster	700 g (1.54 lb)
