The 400GBASE-LR4 module, Duplex LC connector, up to 10km over parallel single-mode fiber. It is compliant to IEEE 802.3bs protocol and 400GAUI-8/CEI-56G-VSR-PAM4 standard.
The 400 Gigabit Ethernet signal is carried over four CWDM grid optical wavelengths. Multiplexing and demultiplexing of the four wavelengths are managed within the device.
Specifications
NVIDIA Ethernet Compatible | MMS1V90-WR | Vendor Name | Longline |
Form Factor | QSFP-DD | Max Data Rate | 400Gbps |
Wavelength | 1271nm,1291nm,1311nm,1331nm | Max Cable Distance | 10km |
Connector | Duplex LC (UPC) | Media | SMF |
Transmitter Type | CWDM EML | Receiver Type | PIN |
TX Power | -2.8~4.0dBm | RX Power | -9.1~4.0dBm |
Powerbudget | 6.3dB | Modulation | 8x 50G PAM4 |
Power Consumption | ≤10W | Extinction Ratio | 3.5dB |
DDM/DOM | Supported | Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
DSP | TX and RX | Inbuilt FEC | No |
Core Size | G.652/9um | Packaging Technology | COB |
Protocols | IEEE 802.3bs, QSFP-DD MSA, CMIS 4.1 | Warranty | 5 Years |
AÇIKLAMA
- Ürünler faturalı olarak tarafınıza gönderilecektir.
- Ürünler 2 yıl süreyle garantilidir.
- Ürün iade süresi 14 gün olup, iade durumunda kargo bedeli alıcıya aittir.
- Saat 16:00'ya kadar verilen siparişler aynı gün kargoya verilir.
- Pazartesi - Cuma 09:00-18:00 mesai saatleridir..
ARAYIPTA BULAMADIĞINIZ TÜM NETWORK VE SERVER YEDEK PARÇALARINI TEDARİK EDİYORUZ
