Item | Specification |
Chassis height [U] | 1 U |
Typical power consumption [W] | 20.5 W |
Typical heat dissipation [BTU/hour] | 69.95 BTU/hour |
Maximum power consumption [W] | 22 W |
Maximum heat dissipation [BTU/hour] | 75.07 BTU/hour |
Static power consumption [W] | 13.0 W |
MTBF [years] | 71.82 years |
MTTR [hours] | 2 hours |
Availability | > 0.99999 |
Noise at normal temperature (acoustic power) [dB(A)] | Noise-free (no fans), < 30 |
Noise at normal temperature (acoustic pressure) [dB(A)] | Noise-free (no fans), < 20 |
Number of card slots | 0 |
Number of power slots | 0 |
Number of fans modules | 0 |
Redundant power supply | Not supported |
Long-term operating temperature [°C(°F)] | –5°C to +45°C (23°F to 113°F) at an altitude of 0 to 1800 m (0 to 5905.51 ft.) |
Restriction on the operating temperature variation rate [°C(°F)] | When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Devices cannot start when the temperature is lower than 0°C (32°F). When the following optical modules are used, the device can operate in the temperature range of –5°C to +40°C (23°F to 104°F): · 10GE non-industrial optical module with a transmission distance of 10 km · Non-industrial FE/GE optical module with a transmission distance of 40 km or 80 km |
Storage temperature [°C(°F)] | –40°C to +70°C (–40°F to +158°F) |
Long-term operating relative humidity [RH] | 5% to 95%, noncondensing |
Long-term operating altitude [m(ft.)] | 0-5000 m (0-16404 ft.) |
Storage altitude [m(ft.)] | 0-5000 m (0-16404 ft.) |
Power supply mode | AC built-in |
Rated input voltage [V] | AC input: 100 V AC to 240 V AC, 50/60 Hz |
Input voltage range [V] | AC input: 90 V AC to 290 V AC, 45 Hz to 65 Hz |
Maximum input current [A] | 0.8 A |
Memory | 512 MB |
Flash memory | 512 MB |
Console port | RJ45 |
Eth Management port | Not supported |
USB | Not supported |
RTC | Not supported |
RPS input | Not supported |
Service port surge protection [kV] | Common mode: ±7 kV |
Power supply surge protection [kV] | ±6 kV in differential mode, ±6 kV in common mode |
Ingress protection level (dustproof/waterproof) | IP20 |
Types of fans | None |
Heat dissipation mode | Natural heat dissipation |
Airflow direction | - |
PoE | Not supported |
Certification | EMC certification Safety certification Manufacturing certification |
