HP GIGABIT PCI-E 4xPORT NC364T 435506-003 436431-001 SERVER ADAP

Overview:

The HP NC364T PCI Express Quad-Port Gigabit Server Adapter features four 10/100/1000T Gigabit Ethernet ports on a single card - saving valuable server I/O slots for other purposes. The four ports provide the highest port density available for Proliant servers in a single PCI Express network adapter. The NC364T is ideal for virtualization - security - server consolidation - network segmentation - and other Proliant server applications requiring maximum throughput and port density. The total aggregate throughput of 4Gbps meets the needs for customers desiring high bandwidth but are not yet ready to move to 10 Gigabit Ethernet. The NC364T is a low-profile card with both full height and half height brackets included in the kit. The x4 PCI Express interface is compatible with x4 - x8 - and x16 PCI slots. Tested and proven to meet demanding HP standards - the NC364T provides full driver support on a wide variety of Proliant servers. The adapter ships with teaming drivers for all major operating systems - teaming utilities - multiple VLAN tagging capability - configuration utilities and IPv6 packet transmit and receive support (excluding all offload capabilities).

Specifications:

Category

Proliant Option

Sub-Category

Proliant Network Adapter

Generation

PCI-E

Part Number

435508-B21

Form Factor

Plug-in Card - Low Profile

Interface Compatibility

PCI Express x 4

PCI Specification Revision

PCIe 1.0a

Ports Qty

4 Ports

Cabling Type

RJ-45

Data Link Protocol

Ethernet, Fast Ethernet,Gigabit Ethernet

Data Transfer Rate

1GB/s

Processor

2 x 82571EB - Intel

RAM

256KB
