Standard
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-T
IEEE 802.3ab 1000Base-T
IEEE 802.3z 1000Base-FX
IEEE 802.3af/at
Interfaces
Electrical port?1x?RJ45? 10/100/1000Base-T
Optical port?1x?SFP? 1000Base-FX
Optical port characteristics
Rate?100/1000Mbps
Wavelength?single-mode ?1310nm/1550nm
Multimode?850nm
Transmission distance?single-mode?2Km
Multimode?20/40/60/80Km
Interface type?SFP
Electrical port characteristics
Rate?10/100/1000Mbps adaptive
Working mode?full duplex / half duplex
Transmission distance?0-~100m
Interface type?RJ45
LED
PWR, Link/Act FP, Link/Act TP, 1000M, SPD, POE
Power requirements
Input voltage: DC47~57V
SIze? 94mmx70mmx26mm?L*W*H?
Environmental restrictions
Operating temperature: -20 ~ 60°C (-4 ~ 140°F)
Storage temperature: -20 ~ 70°C (-4 ~ 158°F)
Relative humidity: 5 ~ 90% (non-condensing)
