Applicable standards
IEEE 802.3i 10Base-T IEEE 802.3u 100Base-T
IEEE 802.3ab 1000Base-T IEEE 802.3z 1000Base-SX/LX
IEEE 802.3ae 10GBase-X
IEEE 802.3ad Link Aggregation IEEE 802.3x Flow Control
IEEE 802.1p Priority IEEE 802.1Q VLAN
IEEE 802.1D STP IEEE 802.1w RSTP
IEEE 802.1s MSTP IEEE 802.1p QoS
Protocols
IGMP Snooping, GMRP, GVRP, DHCP, SNMPv1/v2c/v3, TFTP, NTP, SNTP, Ping, Traceroute, RMON, HTTPS, SSH, Telnet, Syslog, ERPS, MLD, LLDP, LACP, ACL, VRRP, RIP, OSPF, BGP, IS-IS, PIM
MIB: MIB-II, BRIDGE MIB, Ethernet MIB, IF MIB, RMON MIB Group 1, 2, 3, 9
Switching features
QoS queue: 8 Packet forwarding rate: 252 Mpps
VLAN-ID: 1-4094 Back plane bandwidth: 598 Gbps
List of MAC addresses: 8K
Message buffer size: 42 Mbit
Port
Serial port: RS-232 (port type: RJ45 slot)
Gigabit fiber port: 10G/1000 Mbps (port type: SFP slot)
Gigabit copper port: 10/100/1000 Mbps self-adaptive, Full/Half duplex mode, MDI/MDI-X supported.
LED indicator: PWR, Link/ACT, SPD, RUN
Power source requirement
Input voltage: AC220V
Physical properties
Enclosure: Metal IP30
Size: 440 mm*208 mm*44 mm
Weight: 4380 g
Mounting method: Rack-mounted
Environmental restrictions
Working temperature: -40 ~ 45°C (-40 ~ 113°F)
Storage temperature: -40 ~ 85°C (-40 ~ 185°F)
Relative ambient humidity: 5 ~ 95% (non-condensing)
Standards and certification
EMS:
IEC 61000-4-2 ESD level 3, IEC 61000-4-4 EFT level 4, IEC 61000-4-5 Surge level 4
Anti-vibration performance: IEC 60068-2-6
Shock resistance: IEC 60068-2-27
Free fall: IEC 60068-2-32
Certification: CE, FCC, and RoHS
