Specifications Standards IEEE 802.3 IEEE 802.3u IEEE 802.3ab IEEE 802.3z IEEE 802.3x IEEE 802.3ad IEEE 802.3af IEEE 802.1d IEEE 802.1w IEEE 802.1p IEEE 802.1Q IEEE 802.1x IEEE 802.1ab PoE Pin Assignment RJ-45 port # 1~# 8 support IEEE 802.3af End-point, Alternative A mode. Per port provides 15.4 Watts ability. Positive (VCC+): RJ-45 pin 1,2. Negative (VCC-): RJ-45 pin 3,6. Protocol CSMA/CD Status LEDs Power (Green), Power 1 (Green), Power 2 (Green), Fault (Red), Master (Green), FWD (Green) 8 port 10/100: Link/Activity (Green), Full-duplex/Collision (Yellow) SFP port: LNK/ACT(Green), 1000T: LNK/ACT(Green), 1000M(Green) Dimensions Width: 2.8” [72 mm] Depth: 4.1” [105 mm] Height: 5.9” [152 mm] Power Consumption 16 Watts (without PoE) 136 Watts (full PoE) Power Supply External Power Supply: DC 48V, Redundant power DC 48V, removable terminal block Power Input 48 VDC; redundant inputs (removable terminal block), additional barrel connector Ingress Protection IP30 Environment Operating: -40°C to 65°C Storage: -40°C to 85°C Humidity: 5% to 95% (non-condensing) Weight 4 lbs. [1.81 kg] Compliance Safety: UL, cUL, CE EN60950-1 Emissions: FCC Class A Immunity: EN61000-4-2, EN61000-4-3, EN-61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, EN61000-4-11, EN61000-4-12, EN61000-6-2, EN61000-6-4, IEC60068-2-32 (Free fall), IEC60068-2-27 (Shock), IEC60068-2-6 (Vibration)
AÇIKLAMA
Arayıp da bulamadığınız tüm Network ve Server yedek parçalarını tedarik ediyoruz.
(Cisco, Avaya, Lenovo, HP, IBM, Fujitsu, Samsung, Huawei, Enterasys, Juniper, Alcatel, Sun, Qlogic, Dell, Emulex)
