H3C Compatible | SFP-25G-SR-MM850-I | Vendor Name | Longline |
Form Factor | SFP28 | Max Data Rate | 25.78Gbps |
Wavelength | 850nm | Max Cable Distance | 100m@OM4/70m@OM3 |
Connector | Duplex LC | Media | MMF |
Transmitter Type | VCSEL | Receiver Type | PIN |
TX Power | -7.9~1.9dBm | Receiver Sensitivity | ＜-6dBm |
Powerbudget | -1.9dB | Receiver Overload | 2.4dBm |
Power Consumption | ＜1W | Extinction Ratio | ＞2dB |
DDM/DOM | Supported | Industrial Temperature Range | -40 to 85°C (-40 to 185°F) |
CDR | TX & RX Built-in CDR | FEC Function | Support RS-FEC, FC-FEC |
Protocols | IEEE 802.3by, SFF-8472, SFF-8432, SFP28 MSA, CPRI, eCPRI | Warranty | 5 Years |
Core Size | 50/125 µm | Packaging Technology | COB Packaging |
