HP P2000 Dual I/O LFF Drive Enclosure

Installed Devices / Modules Qty:

0

Supported Devices / Modules Qty:

12

Supported Drives:

SATA-300 / SAS-2

Depth:

55.1 cm

Height:

8.9 cm

Weight:

15.5 kg

Width:

44.7 cm

Humidity Range Operating:

10 - 90% (non-condensing)

Max Operating Temperature:

40 °C

Min Operating Temperature:

5 °C

Expansion Bays:

12 (total) / 12 (free) - 3.5" LFF

Interfaces:

4 x SAS 6Gb/s - 26 pin 4x Shielded Mini MultiLane SAS (SFF-8088)

Device Type:

Storage enclosure

Enclosure Type:

Rack-mountable - 2U

Interface Type:

SATA 3Gb/s / SAS 6Gb/s

Cables Included:

2 x SAS cable - 50 cm

Compliant Standards:

VCCI, CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, GS, EN 61000-3-3, EN55022 Class A, CCC, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, WEEE, RoHS, FCC Part 15 A, EN55024 Class A, CAN/CSA C22.2 No. 60950-1-03

Power Device:

2 x internal power supply - hot-plug

Power Redundancy:

Yes

Power Redundancy Scheme:

1+1

Voltage Required:

AC 120/230 V - 50 - 60 Hz
