FORM FACTOR | SFP+ |
CONNECTOR / POLISH | LC-Duplex PC |
INTERFACE | Singlemode |
TYPE | LR |
DISTANCE | 10 km |
TEMPERATURE RANGE | 0°C - 70°C |
BANDWIDTH | 600 Mbit/s - 11.3 Gbit/s |
DIGITAL DIAGNOSTIC MANAGEMENT (DDM) | Yes, internally calibrated |
POWER CONSUMPTION | 1 W |
CDR | none |
SGMII | No |
INBUILT FEC | No |
POWERBUDGET (DB) | 6.2 dB |
TRANSMIT MIN/MAX PER LANE | -8.2 dBm / 0.5 dBm |
RECEIVER MIN/MAX PER LANE | -14.4 dBm / 0.5 dBm (overload) |
WAVELENGTH TX (TYPICAL) | 1310 nm |
WAVELENGTH TX (RANGE) | 1270 - 1355 nm |
WAVELENGTH RX (TYPICAL) | 1310 nm |
WAVELENGTH RX (RANGE) | 1260 - 1565 nm |
LASER | DFB |
RECEIVER TYPE | PIN |
MODULATION | NRZ |
TRANSMIT AND DISPERSION PENALTY | 3.2 dB |
EXTINCTION RATIO | 3.5 dB |
SUPPORTED PROTOCOLS | 10G Ethernet, 10G FC, 8G Fibre Channel, Gigabit Ethernet, LTE 0.614G CPRI, LTE 0.768G OBSAI, LTE 1.22G CPRI, LTE 1.536G OBSAI, LTE 2.458G CPRI, LTE 3.072G OBSAI, LTE 4.915G CPRI, LTE 6.144G CPRI, LTE 6.144G OBSAI, LTE 7.373G CPRI, LTE 9.830G CPRI |
AÇIKLAMA
Arayıp da bulamadığınız tüm Network ve Server yedek parçalarını tedarik ediyoruz.
(Cisco, Avaya, Lenovo, HP, IBM, Fujitsu, Samsung, Huawei, Enterasys, Juniper, Alcatel, Sun, Qlogic, Dell, Emulex)
