The QSFP+ module is designed for use in 40GBASE Ethernet throughput up to 10km over single mode fiber (SMF) using a wavelength of 1310nm via a MTP/MPO connector. It provides high-density and low-power 40GBASE Ethernet solution for data centers, high-performance computing networks, enterprise core and distribution layer applications. It is fully compliant with the QSFP+ MSA.
Note: If this transceiver needs to be used to break out one 40G signal into 4x 10G signals, the interface of the device is required to support the breakout feature.
Specifications
| Arista Networks Compatible | LNG40GBSMMPO-LL | Vendor Name | Longline |
| Form Factor | QSFP+ | Max Data Rate | 44.4Gbps |
| Wavelength | 1310nm | Max Cable Distance | 10km |
| Connector | MTP/MTO-12 Male | Media | SMF |
| Transmitter Type | 4x DFB | Receiver Type | PIN |
| TX Power | -6~-1dBm | Receiver Sensitivity | <-14.4dBm |
| Powerbudget | 8.4dB | Receiver Overload | 0.5dBm |
| Power Consumption | ≤2.5W | Extinction Ratio | >4.5dB |
| Host FEC | Supported | Bit Error Ratio (BER) | 1,00E-12 |
| Commercial Temperature Range | 0 to 70°C (32 to 158°F) | Protocols | 40G Ethernet, MSA Compliant |
