Applicable standards
EEE 802.3 10BaseT
IEEE 802.3u 100BaseT
IEEE 802.3z 1000BaseFX, IEEE 802.3ab 1000BaseT
Switching feature
Back plane bandwidth: 56 Gbps
List of MAC addresses: 8K
Message buffer size: 4.1 Mbit
Port
Gigabit fiber port: 1,000 Mbps
Gigabit copper port: 10/100/1000 Mbps self-adaptive, Full/Half duplex mode, MDI/MDI-X supported, transmission distance 0-100 m
LED indicator: PWR, Link/ACT
Power source requirement
Input voltage: AC220V
Physical properties
Enclosure: Metal, IP30-rated protection
Size: 440*300*44 mm
Weight: 4380 g
Mounting method: Rack-mounted
Environmental restrictions
Working temperature: -20 ~ 75°C (-4 ~ 167°F)
Storage temperature: -40 ~ 85°C (-40 ~ 185°F)
Relative ambient humidity: 5 ~ 95% (non-condensing)
Standards and certification
EMI: FCC Part 15/CISPR22 (EN55022): Class A
EMS:
IEC61000-4-2 (ESD) level 3, IEC 61000-4-3 (RS) level 3, IEC 61000-4-4 (EFT) level 4, IEC 61000-4-5 (Surge) level 4, IEC 61000-4-6 (CS) level 3
Anti-vibration performance: IEC 60068-2-6
Shock resistance: IEC 60068-2-27
Free fall: IEC 60068-2-32
