Cisco WS-C4507R+E -Catalyst 4500E 7 Slot Chassis w/ Dual Power

WS-C4507R+E Specification

Total number of slots

7

Line-card slots

5

Supervisor engine slots

2

Dedicated supervisor engine slot numbers

3 and 4

Supervisor engine redundancy

Yes

Supervisor engines supported

Supervisor Engines 8-E, 8L-E, 7-E, 7L-E, 6-E, and 6L-E

Maximum PoE per slot

1500W

Bandwidth scalability per line-card slot

Up to 48 Gbps on all slots

Number of power supply bays

2

AC input power

Yes

DC input power

Yes

Integrated PoE

Yes

Minimum number of power supplies

1

Power supplies supported

1000W AC

1400W AC

1300W ACV

2800W ACV

4200W ACV

6000W ACV

9000W ACV

1400W DC (triple input)

1400W-DC-P

Number of fan-tray bays

1

Location of 19-inch rack-mount

Front

Location of 23-inch rack-mount

Front (option)

Physical Specifications

Dimensions (H x W x D)

19.19 x 17.31 x 12.50 in. (48.74 x 43.97 x 31.70 cm)

Rack units (RU)

11RU

Chassis weight (with fan tray)

44.50 lb (20.19 kg)

Mounting

19- and 23-in. rack compatible (19-in. rack and cable guide hardware included)
