The Dell 407-BBXT compatible QSFP+ Optical Transceiver Module is designed for use in 40GBASE Ethernet throughput up to 150m over OM4 multimode fiber (MMF) using a wavelength of 832nm to 918nm via an LC connector. It provides high-density and low-power 40GBASE Ethernet solution for data centers, high-performance computing networks, enterprise core and distribution layer applications. It is fully compliant with the QSFP+ MSA, IEEE 802.3ba-2010 40GBASE-ER4.
Dell Compatible | 407-BBXT | Vendor Name | Longline |
Form Factor | QSFP+ | Max Data Rate | 40Gbps |
Wavelength | 832nm - 918nm | Max Cable Distance | 150m@OM4 |
Connector | LC duplex | Media | MMF |
Transimitter Type | VCSEL 850/900nm | Receiver Type | PIN |
DDM/DOM | N/A | Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
TX Power | -4~5dBm | Receiver Sensitivity | <-6dBm |
Power Consumption | 3.5W | Extinction Ratio | 3.5dB |
Modulation Format | NRZ | CDR | None |
Transmit and Dispersion Penalty | 4dB | Powerbudget | 6dB |
Packaging Technology | COB (chip on board) Packaging | FEC Function | Supported |
Protocols | 40G Ethernet, IEEE802.3ba-2010, MSA Compliant | Application | 40 Gigabit Ethernet interconnects, Data Center |
