Cisco CATALYST 3560 48 10/100 + 4 SFP Swith WS-C3560-48TS-S

Rack mounting

Yes

Stackable

No

Form factor

1U

Colour of product

Turquoise

Safety

UL 60950, CAN/CSA C22.2, TUV/GS to EN 60950:2000, CB to IEC 60950, NOM-019-SCFI, CE

Certification

FCC 15 A, EN 55022: 1998 (CISPR22), EN 55024: 1998 (CISPR24), VCCI A, AS/NZS 3548 A, CE, CNS 13438 A, MIC

Switch type

Managed

Switch layer

L2

Quality of Service (QoS) support

Yes

Web-based management

Yes

MIB support

Yes

Number of ports

48

SFP/SFP+ slots quantity

4

SFP module slots quantity

4

Networking standards

IEEE 802.1D, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z

10G support

No

Copper ethernet cabling technology

100Base-TX, 10Base-T

IP routing

Yes

Full duplex

Yes

Broadcast storm control

Yes

Spanning tree protocol

Yes

Flow control support

Yes

Link aggregation

Yes

MAC address table

12000 entries

Supported data transfer rates

10/100 Mbps

Switching capacity

32 Gbit/s

Store-and-forward

Yes

Maximum data transfer rate

0.1 Gbit/s

Jumbo frames support

Yes

DHCP features

DHCP server

Access Control List (ACL)

Yes

IGMP snooping

Yes

Multicast support

Yes

Management protocols

IGMP, RMON, SNMP, Telnet

Internal memory

128 MB

Flash memory

32 MB

Mean time between failures (MTBF)

173400 h

Power consumption (typical)

65 W

Power over Ethernet (PoE)

No

Operating temperature (T-T)

0 - 45 °C

Storage temperature (T-T)

-25 - 70 °C

Operating relative humidity (H-H)

10 - 85%

Operating altitude

0 - 3049 m

Weight

6.1 kg

Management platform

Cisco IOS CLI, Cisco Network Assistant, SAA

Dimensions (WxDxH)

445 x 301 x 44 mm

Connectivity technology

Wired

Power requirements

100-240 VAC, 3.0-1.5A, 50-60Hz

Packet transfer speed

13.1 mpps

Acoustic pressure emissions

48 dB
